Cableaway's Floor Pedestal Outlets raise power and data connections above floor level, ideal for open-plan offices, retail, and exhibition spaces where a floor-flush box isn't practical or where outlets need to be more visible and accessible.
The FP Series is available as a blank pedestal, with 2 x DGPO, or 2 x DGPO plus 2 data provisions, and in a back-to-back configuration doubling outlet capacity for shared workstations or island benches. The Gnome and Super Gnome Series provide a compact stainless steel pedestal alternative, while the AFB-20 and AFB-70 above-ground floor box ranges offer blank and back-to-back blank pedestals in a choice of finishes — pearl white, black ripple, stainless steel, natural anodised, and oyster grey — to suit the surrounding décor.
All floor pedestal outlets are designed to sit above the finished floor level, keeping cabling contained while giving easy access to power and data at bench height.
Cableaway's Floor Pedestal Outlets raise power and data connections above floor level, ideal for open-plan offices, retail, and exhibition spaces where a floor-flush box isn't practical or where outlets need to be more visible and accessible.
The FP Series is available as a blank pedestal, with 2 x DGPO, or 2 x DGPO plus 2 data provisions, and in a back-to-back configuration doubling outlet capacity for shared workstations or island benches. The Gnome and Super Gnome Series provide a compact stainless steel pedestal alternative, while the AFB-20 and AFB-70 above-ground floor box ranges offer blank and back-to-back blank pedestals in a choice of finishes — pearl white, black ripple, stainless steel, natural anodised, and oyster grey — to suit the surrounding décor.
All floor pedestal outlets are designed to sit above the finished floor level, keeping cabling contained while giving easy access to power and data at bench height.
The FP121SS is a simple and cost-effective above-ground floor pedestal outlet box providing a blank chassis for custom outlet configuration. Fitted with a 304 Brushed Stainless Steel cover over a Galvanised Steel body. Accepts standard series-style power, data, and AV outlets. Designed for floor or table surface mounting in commercial, corporate, and hospitality environments. Compact single-width format: W 120 × H 80 × D 95mm.
The FP121SS-4P is a simple and cost-effective above-ground floor pedestal outlet delivering 2 x Standard Double GPOs (4 individual 10A outlets) at floor or table level. Fitted with a 304 Brushed Stainless Steel cover over a Galvanised Steel body. Ideal for commercial, corporate, and hospitality environments where clean, accessible power distribution is required at the point of use. Compact single-width format: W 120 × H 80 × D 95mm.
The FP121SS-2P2D is an above-ground floor pedestal outlet combining 2 x Standard Double GPOs with 2 x Data Provisions in a single compact enclosure. Fitted with a 304 Brushed Stainless Steel cover over a Galvanised Steel body. Delivers power and data connectivity at floor or table level — ideal for open-plan offices, boardrooms and training rooms. Single-width format: W 120 × H 80 × D 95mm.
Formerly part of the Esco product range, the Gnome Series is a stainless steel flush-mounted floor outlet and service box designed for commercial, hospital, and healthcare environments. The single Gnome is designed for easy access to power and data in floor or riser installations. Available unloaded, loaded with 1 x Double GPO 10A, or loaded with 1 x GPO + 2 x Data Provisions. Dimensions: 121mm W × 95mm D × 81mm H.
The FP141SS is a double-width back-to-back floor pedestal outlet box providing a blank chassis for custom outlet configuration on both sides. Fitted with a 304 Brushed Stainless Steel cover over a Galvanised Steel body. Accepts standard series-style power, data, and AV outlets. Ideal for island installations in open plan offices, boardrooms, and hospitality environments. Double-width format: W 240 × H 80 × D 95mm.
The FP141SS-8P is a double-width back-to-back floor pedestal outlet delivering 4 x Standard Double GPOs (8 individual 10A outlets) — 2 GPOs per side. Fitted with a 304 Brushed Stainless Steel cover over a Galvanised Steel body. Ideal for island workstations, central meeting tables, and open-plan environments where power must be accessible from both sides. Double-width format: W 240 × H 80 × D 95mm.
The FP141SS-4P4D is a double-width back-to-back floor pedestal outlet combining 2 x Standard Double GPOs with 4 x Data Provisions in a single enclosure. Fitted with a 304 Brushed Stainless Steel cover over a Galvanised Steel body. Provides power and data connectivity from both sides — perfect for central meeting tables, island workstations, and collaborative environments. W 240 × H 80 × D 95mm.
Formerly part of the Esco product range, the Super Gnome is a double-width stainless steel flush-mounted floor outlet and service box designed for commercial, hospital, and healthcare environments. Designed for easy access to power and data in floor or riser installations. Available unloaded, or loaded with 2 x Double GPO 10A + 2 x 2 Gang Data Plates (4 x data provisions). Dimensions: 238mm W × 95mm D × 81mm H.
The AFB20-WH is an above-ground floor box with a Pearl White powder-coated cover providing 2 x Standard Series power/data/AV outlet provisions. The steel body is manufactured from Galvanised Steel with a cover of Stainless Steel or Aluminium (powder coated). Suitable for floor and bench mounting applications. Dimensions: 127 × 110 × 110mm.
The AFB20-BR is an above-ground floor box with a Black Ripple powder-coated cover providing 2 x Standard Series power/data/AV outlet provisions. The steel body is manufactured from Galvanised Steel with a cover of Stainless Steel or Aluminium (powder coated). Suitable for floor and bench mounting applications. Dimensions: 127 × 110 × 110mm.
The AFB20-SS is an above-ground floor box with a Bright Silver / Stainless Steel finish providing 2 x Standard Series power/data/AV outlet provisions. The steel body is manufactured from Galvanised Steel with a Stainless Steel or Aluminium cover. Suitable for floor and bench mounting applications. Dimensions: 127 × 110 × 110mm.
The AFB20-NA is an above-ground floor box with a Natural Anodised aluminium cover providing 2 x Standard Series power/data/AV outlet provisions. The steel body is manufactured from Galvanised Steel with an Aluminium cover in a natural anodised finish. Suitable for floor and bench mounting. Dimensions: 127 × 110 × 110mm.
