50 X 100mm X 3.0m 2 CHANNEL DROP IN LID SECTION (Black)

50 X 100mm X 3.0m 2 CHANNEL DROP IN LID SECTION (Black)

50mm x 100mm x 2 Division skirting duct drop in lid section. 1.2m Length Black finish.





SDDL100B


Secure Payments are easier than ever! Stripe's payment solutions



Delivery Option’s, you choose from our list of delivery partners



Manufactures warranty on all Cableaway sold products.

The SDDL100B is the drop-in lid section for Cableaway's 50mm x 100mm, 2 Division SD Series aluminium skirting duct in a Satin Black finish, supplied in 1.2m lengths. It drops into the duct body channel to conceal and protect power and data cabling, and can be lifted out for easy access when cables need to be added or serviced.

TECHNICAL SPECIFICATIONS

Component Drop-In Lid Section
Suits Duct Size 50mm x 100mm, 2 Channel
Standard Length 1.2m
Material Aluminium extrusion
Finish Satin Black
Fitting Style Drop-in, removable for cable access
Compatible Body Matching SD Series duct body, sold separately

KEY FEATURES

● Drops into duct body channel for a clean, concealed finish
● Removable for fast access to cabling
● Matches Cableaway's SD Series skirting duct body profile
● Available in Satin Black to suit matching duct finish
● Part of Cableaway's SD Series aluminium skirting duct system

TYPICAL APPLICATIONS

● Commercial Office Fit-Outs ● Small to Medium Projects
● Home Office Cable Management ● Retail and Hospitality Fit-Outs
● Reticulation of Power & Data Cabling ● Data, AV & Multimedia Outlet Housing

ORDERING INFORMATION

Part Number SDDL100B
Series SD Series Aluminium Skirting Duct
Warranty Manufacturer's warranty
SDDL100B

Download

SD Series Skirting Duct

From large commercial offices to your small home office, Cableaway’s skirting duct range is by far the easiest method of housing and distributing of power and data cabling.

Download (400.84KB)

SD501002D DROP IN LID

Download (66.53KB)
